48 PORT CAT5e UNSHIELDED PANEL

https://www.cablek.com/web/image/product.template/46593/image_1920?unique=247b13f

109.90 $ 109.9 CAD 109.90 $

109.90 $

Select to see options

This combination does not exist.


Internal Reference: PTN-TC-P48C5E

Category 5 Enhanced 48 Port Patch Panels - Termination 110 style

These  12, 24, and 48 Port Cat. 5e Unshielded Patch Panels are an ideal solution for Ethernet, Fast Ethernet applications , support a 350MHz connection, and provide color coded labeling for T568A and T568B wiring termination schemes.

May also support GigaEtherrnet 1000Mbs.     Quick & easy termination:   IDC terminal blocks are compatible with our CT-110 tool   Features:

  • Wiring standards  T568A & T568B
  • Network Media  Cat. 5e
  • Backwards compatible to Cat3, 4 and 5
  • Termination tool: CT-110
  • Certifications  CE, FCC
  • Labelling area above each port
  • Cat. 5e transmission performance compliant with ANSI, ISO/IEC 11801, TIA/EIA 568 B.2 standards
  • Nylon cable ties and holders included
  • 1-year limited warranty
