CAT6 (550MHz) PTNB Solide 23AWG CMR - 1000pds
Cat 6 Giga Data Solid Cable - CABLEK
Category 6 is a TIA/EIA 568-C.2 compliant 4-pair UTP cable at a cost effective price.
4 Pair / 23 AWG, CMR, CAT6 - Splineless, Riser, Non-Plenum, Unshielded, Twisted-Pair, Indoor, 250MHZ, 300V - Blue - Pull Pack Length: 1000 ft.
| Physical Characteristics | |
| Pair Count | 4 |
| Conductor | 23 AWG (0.57 mm) Solid Annealed Bare Copper |
| Insulation | Riser: Thermoplastic |
| Jacket Material | Riser: Flame Retardant PVC |
| Nominal Diameter | 0.22 in (5.6mm) |
| Nominal Weight lbs/kft (kg/km) | 22 (33) |
| Electrical Parameters | |
| Attenuation (dB/100m) @ 250 MHz | 32.8 |
| Input Impedance (Ù), nominal | 100 |
| Delay Skew (ns/100 m), maximum | 45 |
| Velocity of Propagation (%), nominal | Riser: 68 |
| DC Resistance (Ù/100 m), maximum | 9.38 |
| Resistance Unbalance (%), max. | 3.0 |
|
Standards Compliance |
|
UL Verified to Category 6 |
|
UL 444 |
|
UL Listed CMR (UL 1666) |
|
UL Listed CMP (NFPA 262) |
|
ISO/IEC 11801 |
|
ANSI/TIA/EIA 568-B.2-1 |
|
ANSI/TIA 568-C.2 |
|
ANSI/ICEA S-90-661-2002 |
|
RoHS Compliant |
The cable utilizes Countdown footage marking which allows the installer to determine the remaining length of cable in the box.
Spécifications
| couleur | Noir ou Bleu ou Gris ou Vert ou Orange ou Violet ou Rouge ou Blanc ou Jaune |
| Longueur | 1000' |
