HI-FLEX CAT6A, noir, 26AWG, 7/34, blindage double

HI-FLEX CAT6A, Black, 26AWG, 7/34, Foil & Braid Shield

• Conductor: 26 awg 7/34 stranded tinned copper .019"
• Insulation: high density polyethylene, .009" nom. wall thickness .036"
• Pairs: color coded singles twisted into pairs .072"
• Cable: (4) twisted pairs twisted together with a central spline and wrapped with a foam polypropylene tape to form a cable core. .176"
• Shields: an overall shield of 38 awg tinned copper braid (80% minimum coverage) shall be applied over the cable core. An aluminized polyester foil shield (foil in, 100% coverage) shall be applied over the braid shield. .195"
• Jacket: polyurethane, black, .022" nom. wall thickness (pressure)
• overall cable diameter .239" nom. (± .010")
