DVI-I MALE SOLDER W/ HOOD
Internal Reference:
DVI-IMS-KIT-B
Thumbscrews DVI Digital/Analog 29 Conductor Male Solder Connector + DVI Hood for 9.5mm Diameter Cable
Kit includes:
- One (1) Male Solder Connector
- One (1) DVI Hood
- One (1) EMI Metal Hood
- Two (2) Thumbscrews
Material:
Connector Housing: Glass-Filled TP BLACK
UL94 V-0 Class
Contacts: Brass
Shell: Steel, Tin-plated over Ni
Electrical Specifications:
Voltage Rating: 500 V AC R.M.S.
Current Rating: 1,5 Amp
Insulation Resistance: 1000 MÙ Min.
Contact Resistance: 20 mÙ Max. (Initial)
Operating Temperature: -20°C to +85°C
